RapID

Overviewback to top

Devices RapID, a new generation of portable devices that can detect Raman spectroscopy to identify the raw materials on a variety of packaging materials such as containers, non-transparent and colored and laminated paper and plastic packages as well.

Some of the features RapID devices include:

Portable Raman ID through opaque and coloured sacks, tubs and bottles
100% ID testing for all incoming containers
Faster ID testing workflow
Reduce operator time and sample-handling booth usage
No contamination - Better for quality and operator exposure
Compatible with most containers, APIs and excipients

High volumes of materials in opaque containers can create a bottleneck in pharmaceutical manufacturing as a dedicated sampling area is needed to open, sample, test and re-seal each container to verify the content identity. RapID allows the operator to verify the contents of each container in the warehouse in seconds without opening, sampling or re-sealing, enabling release immediately into production. This saving on handling and lab testing reduces the overhead from hours or days to only minutes per batch.

To view the video to see the speed of Operations of the system:

Some of the advantages of sterile injectable products RapID production include:

Avoid the samples, maintain sterile and prevent pollution
guarantee free of goods and raw materials from bacteria or impurities s
API users without risk for the user to identify the toxic because of the lack of packaging Packaging
Compatible with a wide range for containers

Device Operations RapIDback to top

Unique technology SORS

Cobalt now with SORS technique RapID device has been produced. The system for the identification and control of raw materials for non-destructive acts. Raman spectroscopy a unique chemical information to identify drug offers. This method is as reliable and ideal technique for the detection and control of medicinal products by European and American standards Pzyrfthshdhast. Hsayst This technique allows for errors in determining the chemical composition similar to a minimum.

Status and application RapID, the environment, food storage / warehouse is. User button RapID gun Raman spectra obtained material and the system automatically selects the best item from the library to identify materials. Then accept or reject the test device with a full report on factory network system records

If you need to add Raman spectra library This process is done in a few minutes. Training, accreditation and the friendly customer additions beam by trained and the training provided by your users are able to edit library.

Add to Library RapID process Raman spectrum are as follows:

Train – Through a simple process a series of scans/measurements are taken and a ‘model’ spectrum for the material within its container is built. RapID can be trained on a new material in under 30 minutes.
Validate – Library items are validated through a series of further measurements (guided by software), and are cross-checked against all other RapID production libraries to ensure similar materials do not provide a false ID of the new material. A detailed report containing the new library information is produced for QC sign-off, including spectral training data for each measurement and statistical results.
Release to Production – The QC manager or responsible person then reviews and releases the new material library to production, all in the RapID software. All data, including the Training and Validation reports are stored electronically to provide evidence of regulatory compliance.

Technical Specificationsback to top

Technical Specifications RapID

Dimensions:

394 mm wide

693 mm Height

630 mm deep

The RapID system consists of a standalone LiteThru™ Engine and the RapID probe head, which are coupled by an integrated ruggedized cable. The probe head comprises a barcode reader and the spectroscopic measurement optics.

Intensity laser	Class 3B, 830 nm
Power	90-132 / 180-264 VAC, 47-63Hz
Software	Includes RapID software Windows 7 Pro OS 21 CFR Part 11 compliant
Hardware	Touchscreen operated Integral barcode scanner (1D and 2D)
Connection	Domain/network via RJ-45 or WiFi USB 2.0

Catalogueback to top

Through-Container ID Verification of Polysorbates 20, 40, 60 , 80 with RapID

Here will be explained

Application of SORS (RapID) to In-Container Testing of Raw Materials for PIC/S GMP Annex 8

Here will be explained
